Wire to wire connectors type Chinese manufacturer

Can replace 222 series connector, easy to use, handle color can be customized.
  • Brand:

    OLINK
  • Item no.:

    PCT-212
  • Payment:

    Wire transfer, PayPal, Western Union, Alipay
  • Product origin:

    China
  • Color:

    Gray/Orange (handle color can be customized)
  • Goods stock:

    500000
  • Min order:

    100
  • Product weight:

    3
  • Shipping port:

    Xiamen, Ningbo,shenzhen,shanghai
  • Lead Time:

    7

wire to wire connectors type Chinese manufacturer

wago 222 connectors

  Specifications of Wire To Wire Connectors

Roduct Name:   wire to wire connectors
Application:   Junction box/electric power
Wiring method:   Insert Crimp
Wire type:   Hard/Flexible wire
Strip length:   9-11mm/0.39in
Cross section:   0.75 - 2.5(4.0) mm2
Voltage(max.):   400V
Rated Current:   20A
Shell material:   Nylon/PC
Conductive material:   Tinned phosphor bronze

 Details Of Push In Connector


Carefully Crafted,Focused On Detail




Tinned Copper Contacts,

Stronger Conductivity

With Test Hole
Measure Whether It Is Electrified
Flame Retardant Nylon
UL94 V-0
Nickel Chromium Spring Steel
Higher Strength And Elasticity


  Description of wire to wire connectors

The wire to wire conenctos can be reused and the wiring is reliable. The shell is made of flame-retardant material to prevent fire, and there is a copper nickel-plated conductive sheet inside, which has good conductivity。


  How To Use Of Push In Connector

Easy Operation,Easy To Insert,Convenient, Fast,Safe And Reliable




Strip Wire 9-10mm Push Up Lever,Align the wires with the holes
Insert Conductor And Push Down Lever
Wiring completed

  Features of Push In Connector

  • Small size and reusable;
  • Use copper-plated nickel (tin-plated) conductive strips for better contact and conductivity;
  • The shell is made of nylon or PC, and the flame retardant grade is UL94 V-0;
  • The clip is made of nickel-chromium spring steel, which has strong durability and good wire fixing ability;
  • The color of the handle of this wire-to-wire connector can be customized to distinguish incoming wires.


  More Push In Wire Connector


*For more information, please contact us by email or through any contact information on the webpage.

Related products
wire connector types
Building junction box electrical wiring connectors
A professional wire connector provider with large supply capacity, short delivery time and favorable prices.
222-413 wire connector
Equivalent 222-413 Series 3 Pin Lever Small Wire Connector
Can replace 222 series connector, easy to use, handle color can be customized.They are used for junction box
Electrical crimp connectors
Push In Fast Terminal Block 222-415 Wire Connectors
222-415 Wire Connectors is durable, insulated, safe, reusable. Widely used in a variety of electrical products, lighting, junction box, control board early warning system, lighting equipment, renovation and home wiring wiring equipment and other fields.
Wire to wire connector
SPL-2 wire to wire connector PCT-2-2 compact connecting terminal
SPL-2 wire to wire connector are widely used in lighting fixtures. With fast connect and disconnection solution
Wire to wire connector
SPL-3 two way 6 ports quick push-in wire connector
SPL-3 inline cable connectors are widely used in home appliances, building wiring and machinery wire connecting parts
push in wire connector
Push in wire to wire connector din rail types PCT-211
Din rail connector: PCT-211 can replace uk series, screwless design. There are accessories- metal bar, rubber button and screws, can be use with the connector make it into multi-pole.
Compact splicing connector
Compact splicing push in wire connector 3 way green color
This push in connector is 1 in 3 out, which is different from 222 series connector. It can be combined into 2 in 6 out, 3 in 9 out, 4 in 12 out and also 5 in 15 out etc. Easy to setup.
32 amp 2 way split wire to wire connector
32 amp 2 way split wire to wire connector
This push in connector is 1 in 2 out, which is different from 222 series connector. It can be combined into 2 in 4 out, 3 in 6 out, 4 in 8 out and also 5 in 10 out etc. Easy to setup.
