 /Russian Aviation Mil Spec 24V Female Round 4P/10 Pin Power Cord Connector Industrial Miniature DC for Connection

Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections
Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections Secure Female Power Connector - For Russian Aviation Ground Equipment, Industrial Miniature DC Connections

Russian Aviation Mil Spec 24V Female Round 4P/10 Pin Power Cord Connector Industrial Miniature DC for Connection

OHS Series Connector Was Developed According Tothe Russia Type Ohц-b C-1(2),Widely Used In Direct Current And Alrernate Currentcircuit,the Connect Way Is Bayonet ,Receptcle without Tail ,plug With Plastic Straight Tail.

  • Brand:

    OLINK

  • Item no.:

    OHS

  • Payment:

    T/T

  • Product origin:

    China

  • Color:

    Gold

  • Min order:

    10

  • Lead Time:

    10
Inquiry now
10 pin connector power supply

PRODUCT INTRODUCTION
OHS Series Connector Was Developed According Tothe Russia Type Ohц-b C-1(2),Widely Used In Direct Current And Alrernate Currentcircuit,the Connect Way Is Bayonet ,Receptcle without Tail ,plug With Plastic Straight Tail.
power connector rond
PRODUCT PARAMETERS
Shell material
 aluminum alloy
 Connection type
 Threaded connection
Wiring method
 Welding
 Working temperature
 -60℃~+85℃
Rated voltage
 250V
 Contact Resistance
 ≤5mΩ
Vibration
 1-5000Hz 20g
 Insulation Resistance
 ≥1000MΩ
Shock
 1000g (single times), 100g (multiple times
 Contact Diameter
 Φ1.0mm
OPERATING VOLTAGE AND CURRENT
Shell No.
 Number of contacts
 Working current(A)
 Operating voltage(V)
10
 4 3.7 250V
12 7 3.1 250V
14 10 3.0 250V
18 19 2.1 250V
22 32 1.8 250V
27 50 1.5 250V
connector power 4p
PRODUCT NAMING AND CODES
cable power connector
panel mount power connectorindustry power connector
Note: If You Need Detailed Size Drawings, Please Contact Our Customer Service Staff For Consultation, We Will Provide You With Professional Answers!
straight orientation connectoralloy material connector
