Brand:
F&CItem no.:
F3C-08KN/EN02-N/P/N2Product origin:
China
| standard shell/shield | F3C-08KS01-N R2M | NPN.NO | 1mm | 8×8×1(iron) | φ3×2M/3-wires |
| F3C-08KS01-N2 R2M | NPN.NC | ||||
| F3C-08KS01-P R2M | PNP.NO | ||||
| F3C-08KS01-P2 R2M | PNP.NC | ||||
| standard shell/non-shield | F3C-08KN02-N R2M | NPN.NO | 2mm | 8×8×1(iron) | φ3×2M/3-wires |
| F3C-08KN02-N2 R2M | NPN.NC | ||||
| F3C-08KN02-P R2M | PNP.NO | ||||
| F3C-08KN02-P2 R2M | PNP.NC | ||||
| short shell/shield | F3C-08ES01-N R2M | NPN.NO | 1mm | 8×8×1(iron) | φ3×2M/3-wires |
| F3C-08ES01-N2 R2M | NPN.NC | ||||
| F3C-08ES01-P R2M | PNP.NO | ||||
| F3C-08ES01-P2 R2M | PNP.NC | ||||
| short shell/non-shield | F3C-08EN02-N R2M | NPN.NO | 2mm | 8×8×1(iron) | φ3×2M/3-wires |
| F3C-08EN02-N2 R2M | NPN.NC | ||||
| F3C-08EN02-P R2M | PNP.NO | ||||
| F3C-08EN02-P2 R2M | PNP.NC | ||||
| standard shell/shield/double sensing range | F3L-08KS02-N R2M | NPN.NO | 2mm | 8×8×1(iron) | φ3×2M/3-wires |
| F3L-08KS02-N2 R2M | NPN.NC | ||||
| F3L-08KS02-P R2M | PNP.NO | ||||
| F3L-08KS02-P2 R2M | PNP.NC | ||||
| standard shell/non-shield/double sensing range | F3L-08KN04-N R2M | NPN.NO | 4mm | 12×12×1(iron) | φ3×2M/3-wires |
| F3L-08KN04-N2 R2M | NPN.NC | ||||
| F3L-08KN04-P R2M | PNP.NO | ||||
| F3L-08KN04-P2 R2M | PNP.NC | ||||
| short shell/shield/double sensing range | F3L-08ES02-N R2M | NPN.NO | 2mm | 8×8×1(iron) | φ3×2M/3-wires |
| F3L-08ES02-N2 R2M | NPN.NC | ||||
| F3L-08ES02-P R2M | PNP.NO | ||||
| F3L-08ES02-P2 R2M | PNP.NC | ||||
| short shell/non-shield/double sensing range | F3L-08EN04-N R2M | NPN.NO | 4mm | 12×12×1(iron) | φ3×2M/3-wires |
| F3L-08EN04-N2 R2M | NPN.NC | ||||
| F3L-08EN04-P R2M | PNP.NO | ||||
| F3L-08EN04-P2 R2M | PNP.NC |
| Response frequency | 1000Hz/800Hz |
| Hysteresis | 10%≤sensing distance |
| Operating voltage | DC:12~24VDC±10%/ can customize 5V |
| Current consumption | DC:≤8mA No—Load |
| Load current | DC:24V 150mA Max |
| Leakage current | DC:≤0.01mA no-Load |
| Residual votage | DC:≤1.5VDC No-load |
| Operating temperature | -20°C~+70°C |
| Material | PBTand SUS304 |
| Wiring method | 2M/3-wires |
| Protection degree | IP67 |
