Brand:
F&CItem no.:
F3N-11TN04-N/P/N2/P2Product origin:
China
F3N-11TN04-N R2M
NPN.NO
▆▆▆ 4mm
10×10×1(iron)
φ3×2M/3-wires or 150mm with M8 connector
F3N-11TN04-N2 R2M
NPN.NC
F3N-11TN04-P R2M
PNP.NO
F3N-11TN04-P2 R2M
PNP.NC
F3N-11TN04-B R2M
two-wires.NO
F3N-11TN04-B2 R2M
two-wires.NC
F3N-11DN04-N R2M
NPN.NO
F3N-11DN04-N2 R2M
NPN.NC
F3N-11DN04-P R2M
PNP.NO
F3N-11DN04-P2 R2M
PNP.NC
F3N-11DN04-B R2M
two-wires.NO
F3N-11DN04-B2 R2M
two-wires.NC
Specifications for dc current sensors :
| Small square proximity switch | |
| Induction Direction | Model |
| Front induction |
F3N-11TN04-N R2M F3N-11TN04-N2 R2M F3N-11TN04-P R2M F3N-11TN04-P2 R2M F3N-11TN04-B R2M F3N-11TN04-B2 R2M |
| Above induction |
F3N-11DN04-N R2M F3N-11DN04-N2 R2M F3N-11DN04-P R2M F3N-11DN04-P2 R2M F3N-11DN04-B R2M F3N-11DN04-B2 R2M |
| Detection distance | 4mm |
| Recommand distance | 3.2mm |
| Standard sensing object | 10*10*1(iron) |
| Response frequency | 600Hz |
| Hysteresis | no more than 10% Detection distance |
| Operating voltage | 12-24VDC 10%/(customize 5V) |
| Current consumption | less than 10mA |
| Load current | 24V 100mA Max |
| Leakage current | less than 0.01mA No-load |
| Residual voltage | less than 1.0VDC |
| Operating Temperature | -25 TO +70 |
| Waterproof degree | IP67 |
| Material | ABS |
| Wiring method |
φ2.8×2M/3-wires φ3×2M/3-wires φ3×2M/2-wires |
Features and advantages for dc current sensors:
1. Easy to install with limited space.
2. Many models for choice like top sensing, front sensing.
3. High quality usage to resistant oil, water,dust.
4. OEM order accepted.
