High-Level Waterproof Plastic Bayonet Electric Battery Connector IP65 IP67 IP68 Watertight

SP17 connector is the medium sized plastic shell IP68 waterproof connector.

  • Brand:

    OLINK
  • Item no.:

    OL17
  • Payment:

    Wire transfer, Paypal, Western Union, Alipay
  • Product origin:

    China
  • Color:

    Black&Blue
  • Min order:

    10
  • Product weight:

    2
  • Shipping port:

    Xiamen
  • Lead Time:

    7

IP67 Plastic WWateproof Cable Power Connector

  Description Of SP17 Series Connector

  • OL17 cable power connector is widely used in outdoor wire connection.
  • There are 2-9 Pins for your choice.
  • Cutout hole size: 17mm
  • Couoling: Thread
  • Shell Material:  Nylon66, Fire Resistance:V-0
  • Insert Material: PPS Max Temperature 260 degree
  • Contact material: Brass Wigh Gold plating
  • Cable OD: 7-10 mm
  • IP rating: IP67/68


  Drawing of SP17 Cable Connector




1710 (plug) 1711(Coupler)




1712 (Rear Nut Socket) 1713 (Flange Socket) 1714(Square Socket)


  • SP17 Connector There Are 5 Types: Plug, Coupler, Rear Nut socket, Rhombus Flange Socket And Square Socket.
  • Number Of Contack: 2pin 3pin 4pin 5pin 7pin 9pin.
  • Usable cable diameter:7-10mm


  More SP Series Connectors Ave Available



SP13 Connectors SP21 Connectors M20 Connectors(Bayonet,Screw Crimping)

*If you need more information, you can find customer service through the contact information on the right side of this page.
