OL17 IP67/IP68 5-Pin Panel Mount Waterproof Connector

Olink OL17 Industrial Waterproof Connector is a high-performance rectangular bulkhead power adapter with IP67/IP68 waterproof rating. As a reliable solder termination waterproof connector, it features brass gold-plated contacts and durable UL94-V0 nylon housing. Rated at 5A/10A, 500V, with 2-10 pins and 7-10mm cable compatibility, this industrial electrical connector is ideal for male/female connections in harsh outdoor industrial power applications, supporting full OEM/ODM customization and backed by 7×24h global technical support.

Item no.:
OL17
Payment:
Wire transfer, Paypal, Western Union, Alipay
Product origin:
China
Shipping port:
Xiamen
Lead Time:
7

Inquiry now

product introduction

Technical Specifications

Rated Current:	5A/10A
Rated Voltage:	500V
Pin Count:	2P-10P
Contact Material:	Brass With Gold Plating
Shell Material:	Nylon
IP Rating:	IP67/IP68
Flame Retardant Grade:	UL94-V0
Color:	Blue/Black
Insulation Material:	PPS Max
Application Scenario:	Power inverter box/Battery conversion
Seal Ring:	flat sealing ring/Ordinary o-ring seal
OEM/ODM:	YES
Technical Support:	7*24h Online Service

Product selling points

· IP67/IP68 Waterproof Protection: Superior waterproof & dustproof, ideal for harsh outdoor/wet working environments.
· High Voltage & Current Performance: 5A/10A current, 500V AC voltage, meets medium-power power supply needs.
· Premium Durable Connector Materials: Gold-plated brass contacts (low resistance, anti-corrosion), PA66 back shell (UL94-V0 fire resistance), PPS insulation (260℃ high temperature resistance).
· Flexible Industrial Pin Configurations: 2-10 pins optional, compatible with diverse outdoor power connection scenarios.
· Solder & Screw Termination Design: Dual wiring options, fits 4-6.5mm (default) & 5-8mm cable OD for flexible installation.
· Stable Electrical Connector Performance: 2000MΩ insulation resistance, >500 mating cycles, stable work at -25℃ to +85℃.
· Secure Threaded Connection: Threaded coupling design for anti-loosening, ensures stable power transmission.
· Complete Standard Accessories: Dust cover & rubber ring included, random flat/O-ring seals for enhanced sealing.
· OEM/ODM Customizable Connector: OEM/ODM supported (all-black shell, customized wire harness/LOGO).
· Certified Industrial Quality: CE, RoHS certified, strict factory testing for safe and reliable long-term use.
· Factory Direct Cost-Effective Supply: 7-day lead time for 1-5000pcs, bulk price discounts for large orders, factory-direct pricing.
· Wide Industrial Application: Perfect for power inverters, battery converters, outdoor billboards, street lamps and all outdoor electronic power devices.
· Professional Global Technical Support: 7*24h online technical service, free samples available (freight collect).

Product details

OL17 Exploded View and Detailed Parameter Diagram

Waterproof Rubber Seal & Waterproof Cap Display

Application Scenarios

Usage Scenarios

Full OL Series Plastic Waterproof Connectors

OL Series Full Product Display

Factory Display

All-in-one production and customization factory

Certificate Display

Shipping & Payment Methods

We support sea, air and land transportation, with a variety of express delivery options. Payment methods include PayPal, Visa, etc
