OL13 IP68 RV Aviation Connector 1Pin 250V Gold Plated

OL13 IP68 Waterproof Electrical Connector is a high-performance bulkhead mount round adapter designed for harsh industrial and outdoor environments. As a reliable solderable waterproof connector, it features IP68 waterproof protection and UL94-V0 flammability rating for superior safety and durability. With corrosion-resistant nylon housing and brass gold-plated contacts, this industrial electrical connector delivers stable conductivity (3A-25A, 125-400V AC), ideal for power inverters, battery conversion and industrial power systems.
Offered in 1-9 pins and blue/black colors, it fits 4mm-8mm cables with dual sealing rings for enhanced moisture resistance. Fully customizable via OEM/ODM, it supports cable and wiring harness modifications. Backed by 7×24h technical support and 7-day fast delivery, it ensures stable performance for global industrial power applications.

Item no.:
OL13
Payment:
Wire transfer, Paypal, Western Union, Alipay
Lead Time:
7

Inquiry now

product introduction

Technical Specifications

Rated Current:	3A-25A
Rated Voltage:	250V
Pin Count:	1P-9P
Contact Material:	Brass With Gold Plating
Shell Material:	Nylon
IP Rating:	IP67/IP68
Flame Retardant Grade:	UL94-V0
Color:	Blue/Black
Insulation Material:	PPS Max
Application Scenario:	Power inverter box/Battery conversion
Seal Ring:	flat sealing ring/Ordinary o-ring seal
OEM/ODM:	YES
Technical Support:	7*24h Online Service

Product selling points

· IP68 Waterproof Connector: Super IP68 Waterproof Rating: Excellent sealing performance, protects against moisture infiltration for wet/outdoor use, IP67 compatible.
· Gold Plated Conductivity: High-performance Conductivity: Brass contacts with gold plating (1.5-3u), 3A-25A rated current, 250V rated voltage, stable power transmission.
· Industrial Durable Materials: Durable High-quality Materials: Nylon housing, PA66 fire-resistant back shell (V-0), PPS insulation (max 260℃), >500 mating cycles, 2000MΩ insulation resistance.
· Flexible Pin Configuration: Flexible Configuration: 1-9 pin options, 2 cable OD ranges (4-6.5mm/5-8mm), solder/screw termination, threaded coupling, 2 docking methods available.
· Complete Standard Accessories: Complete Standard Accessories: Comes with dust cover, rubber ring and two types of sealing rings (random delivery), no extra purchase needed.
· Wide Industrial Application: Broad Application: Ideal for power supply connections (inverter/battery converter) and outdoor electronics (billboards, street lamps).
· Certified Safe Connector: Certified & Reliable: CE, IP68/IP67, ZRC certified, works in -25℃~+85℃, suitable for harsh environments.
· OEM/ODM Customizable: Customizable Solutions: OEM/ODM supported, all-black shell and cable harness customization available for diverse demands.
· Factory Direct Cost-Effective: Efficient Service & Cost-effective: 7*24h online technical support, 7-day lead time for 1-100 sets, tiered pricing for bulk orders with factory-direct supply.

Product details

The OL13 offers four head types: Front nut type, Rear nut type, Flange type, and Mating type OL13 Connector Exploded View

OL13 Connector Details

Application Scenarios

OL13 Connector Applications

Full OL Series Plastic Waterproof Connectors

Full Range of Waterproof Connectors Display

Factory Display

All-in-one production and customization factory

Certificate Display

Shipping & Payment Methods

We support sea, air and land transportation, with a variety of express delivery options. Payment methods include PayPal, Visa, etc
